    SMTCL CNC Lathe HTC 50n Fanuc Controller Live Tooling Slant Bed CNC Lathe Horizontal CNC Turning Center

    Ask Lasest Price
    Brand Name : SMTCL
    Model Number : HTC 50n
    Certification : CE ISO certification
    Payment Terms : T/T,L/C,,Western Union
    Supply Ability : 50 sets per month
    Delivery Time : 45-60 days
    • Product Details
    • Company Profile

    SMTCL CNC Lathe HTC 50n Fanuc Controller Live Tooling Slant Bed CNC Lathe Horizontal CNC Turning Center

    SMTCL CNC Lathe HTC 50n Fanuc Controller Live Tooling Slant Bed CNC Lathe Horizontal CNC Turning Center

    Product Description:

    Slant bed CNC lathe HTC 50n Full Function CNC Lathe Turning Center
    HTC 50n horizontal CNC lathe can be selected with 45° integral inclined bed, casting by resin sand process, reasonable internal rib layout, wide guide surface, high overall rigidity of the bed, with good torsional performance, smooth chip removal advantages

    Product Features:

    SMTCL CNC Lathe HTC 50n Fanuc Controller Live Tooling Slant Bed CNC Lathe Horizontal CNC Turning Center
    A:High rigidity
    It adopts 45° and 75° high-rigidity integral inclined bed, and all castings are optimized by finite element
    method, which effectively eliminates vibration during machine operation and cutting, enhances reliability, and is easy to
    maintain, enabling customers to obtain durable and stable processing quality.
    SMTCL CNC Lathe HTC 50n Fanuc Controller Live Tooling Slant Bed CNC Lathe Horizontal CNC Turning Center
    B:high precision
    All parts of the machine tool adopt precision grinding parts from well-known manufacturers at home and abroad. The advanced structural design and perfect process measures make the overall layout compact, harmonious, and good rigidity, ensuring that the machine tool has high machining accuracy and long-term accuracy retention.
    SMTCL CNC Lathe HTC 50n Fanuc Controller Live Tooling Slant Bed CNC Lathe Horizontal CNC Turning Center
    C:Pleasant
    Optional overall 75° inclined bed machine tool, equipped with a vertical and horizontal center frame, the center of the spindle is closer to the operator, which is convenient for loading and unloading workpieces and chip removal.
    SMTCL CNC Lathe HTC 50n Fanuc Controller Live Tooling Slant Bed CNC Lathe Horizontal CNC Turning Center
    D:rich configuration
    The machine can be configured with various modules to meet the different needs of customers. Some models can be equipped with power tool tower to become the turning center, with rich configuration and high cost performance.
    Product Paramenters:
    Item
    UNIT
    HTC 50n
    Max. swing over bed
    mm
    Φ650
    Max. swing over carriage
    mm
    Φ500
    Max. cutting diameter (disc/shaft)
    mm
    Φ500
    Max. cutting length
    mm
    500/1000/1500/2000/2500
    Spindle bore diameter
    mm
    Φ80
    Form of spindle nose
    A2-8
    Max. diameter through bar
    mm
    Φ65
    Main motor power (continuous / 30min)
    kw
    22/30
    Range of spindle speed / Max. output torque
    r/min
    35~3000 / 860
    Chuck diameter
    inch
    10”
    Max. travel of X-axis
    mm
    270
    Max. travel of Z-axis
    mm
    600/1100/1600/2100/2600
    Rapid speed (X /Z axis)
    m/min
    12/12
    Form of tool turret
    Horizontal 12-position turret
    Size of tool shank
    mm
    25X25/Φ50
    Positioning accuracy (X axis)
    mm
    0.01
    Positioning accuracy (Z-axis)
    mm
    0.015/0.015/0.020/0.025/0.035
    Repositioning accuracy(X axis)
    mm
    0.005
    Repositioning accuracy(Z-axis)
    mm
    0.007/0.007/0.010/0.013/0.020
    Machining accuracy
    IT6
    Max. weight of disc workpiece
    kg
    200
    Max. weight of shaft workpiece
    kg
    800
    weight of machine
    kg
    5500/7500/9000/11000/12500
    Overall dimensions of machine (LxWxH)
    mm
    4050x2286x2260; 4550x2286x2260; 5050x2286x2260;
    5500x2286x2260; 6050x2286x2260

    Industry application:

    SMTCL CNC Lathe HTC 50n Fanuc Controller Live Tooling Slant Bed CNC Lathe Horizontal CNC Turning Center

    Workpiece example: guide sleeve

    Processing model: HTC50t Workpiece material: 27SiMn Linear speed: 120-180m/min Feed rate: 0.1-8mm/r (including thread) Processing efficiency: 26 minutes
    SMTCL CNC Lathe HTC 50n Fanuc Controller Live Tooling Slant Bed CNC Lathe Horizontal CNC Turning Center

    Workpiece example: medium 500 cylinder

    Processing model: HTC63350t Workpiece material: 27SiMn Linear speed: 120-180m/min Feed rate: 02-10mm/r (including thread) Processing efficiency: 75 minutes
    SMTCL CNC Lathe HTC 50n Fanuc Controller Live Tooling Slant Bed CNC Lathe Horizontal CNC Turning Center

    Workpiece Example: Drive Axle

    Processing model: CQ850n Workpiece material: 40Cr Linear speed: 150-180m/min Feed rate: 0.1-0.3mm/r Processing efficiency: 12 minutes
    SMTCL CNC Lathe HTC 50n Fanuc Controller Live Tooling Slant Bed CNC Lathe Horizontal CNC Turning Center

    Workpiece example: RE2B axle

    Processing model: HTC63n (double turret) Workpiece material: 35CrMo Linear speed: 150-260m/min Feed rate: 0.2-0.5mm/r (including thread) Processing efficiency: 39 minutes.

    OUR Service:

    1. Assemble and debug before delivery


    2. Respond within 24 hours and proceed to deal with the problem.

    3. 1 year free repair service (no-human damage only).

    4. Overall warehousing solution provided
    Why Choose Us:
    ◆ Top quality sense, customers' requests come first

    ◆ 30 years + R & D history, the company was founded in 1993

    ◆ High-tech manufacturer with research anddesign capacity

    ◆ Stable and mature supplying system

    ◆ Young active sales and engineers for instant services(24 hours online)

    ◆ Upgrading on mechanism according to ergonomics and easy maintenance

    ◆ Our structure design principle: easy maintenance & installation, low cost maintenance, not affect production
    About Us:
    SMTCL CNC Lathe HTC 50n Fanuc Controller Live Tooling Slant Bed CNC Lathe Horizontal CNC Turning Center
    Welcome to visit us!
    Shanghai HD M&E Tech Co., Ltd is located in Shanghai, China. We specialize in CNC lathe, vertical machining center, horizontal machining center, gantry machining center, five-axis machining center, turn-milling center and various other CNC equipment. We have more than 200 kinds of machine tools. The quality and technology of products have reached the international advanced level.
    SMTCL and SYMG group is our cooperating factory. It has over 80 years’ history of manufacturing machine tools. The first lathe, drilling machine and boring machine were all born here. They have been one of the leader of China's Machine Tool industry and the largest machine tool manufacture in China. Machine tool products cover automobiles, aviation, new energy, construction machinery, ships, pump valves, bearings, 3C electronics, molds and other industries. We take the mission of providing the machine tools with leading technology, high quality and good service to our customers all over the world!
    Our Factory:
    SMTCL CNC Lathe HTC 50n Fanuc Controller Live Tooling Slant Bed CNC Lathe Horizontal CNC Turning Center
    Exhibition:

    SMTCL CNC Lathe HTC 50n Fanuc Controller Live Tooling Slant Bed CNC Lathe Horizontal CNC Turning Center

    FAQ:

    Q1. Are you a trade company or manufacturing company?

    We are a manufacturing company.
    Q2. What's your main products of your company?
    We specialized in all kinds of machines, such as CNC Lathe, CNC Milling Machine, Vertical Machining Center,Conventional Lathe, Drilling Machine, Radial Drilling Machine, and so on.
    Q3. Can you provide customized machine or SPM (Special purpose machine)?
    Yes, we provide Smart CNC solutions for our customer in order to increase efficiency.
    Q4: What's your warranty terms?
    We will supply a replacement for parts that prove to be defective for a period of 12 months,
    starting on the machine's bill of lading date.
    Q5. What is the services?
    Pr-sales:Customized solutions, planning and design;One-to-one service
    After sales:7 days 24 hours on line service, Remote guidance of installation, docking with customer software system
    Q6: Why choose your company?
    Products from the development, design, manufacture, assembly of the entire production process are
    carried out between plants with a complete production chain which is your most reliable guarantee.
    Q7: Can your company send the technical personnel to our company and direct our workers overseas?
    We can supply this kind of service. When the machines arrive the buyer's installation site, we can timely send mechanical and electrical engineers to install according to the buyer's schedule. All these can be quoted and list in the contract. The seller will cooperate with the buyer to deal with visa and installation preparation before going abroad.
    Q8: What's the Payment Terms?
    T/T 30% initial payment when order, 70% balance payment before shipment. irrevocable letter ofcredit at sight
